Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm

Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
Nema 11 Non-captive 46mm Stack 0.75A Lead 1.27mm(0.05") Length 250mm
0 reviews • Write a review
from
$112.88
10 or more $105.10
100 or more $98.32
  • Model: 11N18S0754FD3-250RS
  • Weight: 0.53kg

Available Options

Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Request a Quote or Ask a Question

Captcha

Custom Design Options

You can select from the customization options listed below.

Lead Screw
Lead, Length, Screw End Machining, Thread Type...
Nut
Material, Profile/Shape, Dimensions...
Body
Body Dimensions, Mounting Holes...
Cable
Length, Connector, Terminal...
Optional Accessories
Encoder, Brake

The motor part is 46mm body 1.8 degree 0.75A Nema 11 stepper motor, and it works with a 4.76mm(0.1874") diameter 250mm(9.8425") length lead screw, the linear travel is 1.27mm(0.05") per revolution. This model is almost exactly same as Haydon Kerk 28000 series size 11 double stack non-captive stepper motor linear actuator.

Electrical Specification

  • Manufacturer Part Number: 11N18S0754FD3-250RS(11N18S0754FD-250RS)
  • Motor Type: Non-captive Linear Stepper
  • Step Angle: 1.8°
  • Minimal Thrust: 59N(300pps)
  • Rated Current/phase: 0.75A
  • Phase Resistance: 6.7ohms
  • Voltage: 5V
  • Inductance: 5.8mH±20%(1KHz)

Physical Specification

  • Frame Size: 28 x 28mm
  • Body Length: 46mm
  • Lead Screw Length: 250mm(9.8425")
  • Lead Screw Diameter: Φ4.76mm(0.1874")
  • Lead/Step: 0.00635mm(0.00025")
  • Lead Travel/Revolution: 1.27mm(0.05")
  • Number of Leads: 4
  • Cable Length: 300mm
  • Weight : 180g

Connection

A+
A-
B+
B-
Red
Red/White
Green/White
Green

● How to order a custom linear motor?  Custom Linear Stepper Motor

● If you only have the old part number, get the new one here  Show Details

● How we named linear motor?  Part Number Construction

Physical Specification
No. of Lead 4
Lead Length(mm) 300
Linear Motor Type Non-Captive
Lead Travel/Revolution(mm) 1.27
Lead Travel/Step(mm) 0.00635
Lead Screw Length(mm) 250
Lead Screw Diameter(mm) 4.76
Frame Size(mm) Nema 11 (28 x 28)
Body Length(mm) 46
Inventory Method Dedicated Inventory
IP Rating 40
Electrical Specification
Minimal Thrust(N) @300pps 59
Rated Current(A) 0.75
Bipolar/Unipolar Bipolar
Step Angle(deg.) 1.8
Phase Resistance(ohms) 6.7
Inductance(mH) 5.8
Has Torque/Thrust Curve? No
